Reasonable price 60 Pin LAN Transformers - Single Port DIP 1000 Base-T 24Pin Lan Transformer G241T002N – Zhusun Detail:

Single Port DIP 1000 Base-T 24Pin Lan Transformer G241T002N

QQ截图20210426105612

Categories  Transformers
 Network Transforme
Transformer Type  ETHERNET(NoN POE)
PIN Contacts  24
Number of Ports  Single Port
Mounting Type  DIP
Turns Ratio - Primary:Secondary  1CT:1CT
Packaging  Tube
Operating Temperature  -40°C ~ 85°C
Comment  SAME AS NL VERSION
Construction  OPEN FRAME
RoHS Compliant  YES-RoHS-5 WIth Lead in Solder Exemption



The scope of application of T568B wire sequence
One, direct connection interconnection
Both ends of the network cable are connected according to T568B
1. Computer←—→ADSL cat
2. ADSL modem ←—→ WAN port of ADSL router
3. Computer ←—→ LAN port of ADSL router
4. Computer ←—→ Hub or Switch
2. Interspersed interconnection
One end of the network cable is connected to T568B, and the other end is connected to T568A.
1. Computer←—→Computer, that is, peer-to-peer network connection
2. Hub ←—→ Hub
3. Switch←—→Switch
   The corresponding relationship between each pin of the RJ-type network cable plug and the color mark of the network cable is:
  Plug pin number network cable color
  1————Orange and White
  2————Orange
  3————Green and White
  4————Blue
  5————Blue and White
  6————Green
  7————Brown and white
   8————Brown






Product detail pictures:

Reasonable price 60 Pin LAN Transformers - Single Port DIP 1000 Base-T 24Pin Lan Transformer G241T002N – Zhusun detail pictures
