RJ45 Integrated Double USB 2.0 Computer connector 08C2-1X1T-03

  • Number of Ports: RJ45+USB
  • Speed: 100 Base-T
  • Application-Lan : NoN PoE
  • Latch: UP
  • LED: With LED
  • Orientation : 90°Angle (Right)
  • Compatible Brand : BEL
  • Mounting Type: Through Hole
  • Shielding: Shielded, EMI Finger
  • Temperature: ﹣40 TO ﹢85

  • Part Number:08C2-1X1T-03
    08C2-1X1T-36
  • Product Detail

    Contact Us

    Product Tags

    Similar Part No

    ARJE-0029 RJ45 Integrated Double USB 2.0 Computer connector

    RJ45 With USB Connector

    Categories  Connectors, Interconnects
     Modular Connectors - Jacks With Magnetics
    Application-LAN  ETHERNET(NoN POE)
    Connector Type  RJ45+2USB 2.0
    Number of Positions/Contacts  8p8c
    Number of Ports  3×1
    Applications Speed  10/100 Base-T, AutoMDIX
    Mounting Type  Through Hole
    Orientation  90° Angle (Right)
    Termination  Solder
    Height Above Board  30.50mm
    LED Color  With LED
    Shielding  Shielded
    Features  Board Guide
    Tab Direction  UP
    Contact Material  Phosphor Bronze
    Packaging  Tray
    Operating Temperature  -40°C ~ 85°C
    Contact Material Plating Thickness  Gold 6.00µin/15.00µin/30.00µin/50.00µin
    Shield Material  Brass
    Housing Material  Thermoplastic
    RoHS Compliant  YES-RoHS-5 WIth Lead in Solder Exemption
